Infrastructure & Facilities


COLD FORGING, HEAT TREATMENT


LMW SMART TURN 165mm 6 Nos

  • A very stable machine and therefore can utilize the cutting tools at their optimum cutting parameters.
  • Rigid structure, the stiffness built into the feed mechanism and higher in-cut time-all contribute to greater man-machine efficiency.
  • The Smarturn Series will help you stick to very demanding delivery schedules of your customer even for small batch production.
  • High speed positioning keep non-cut time to the minimum.

ACE JOBBER XL 250mm, ACE JOBBER JUNIOR 200mm, ACE CUB LM 165mm 9 Nos

Powerful AC Spindle motor. High speed rpm spindle l. Thermally stabilised spindle. Hardened and ground box type.20 m/min rapid traverse rate. Pre-tension ball screw support.0.45 sec.turret Index time. 100% ball bar tested


A-20 Citizen with Automatic Bar feeder 1 Nos

One Quill type rotary tool position and cross-milling spindle (BSC210) comes with machines as standard. The maximum tool spindle speed is 6,000 rpm (rating 4,500 rpm). CS Quick Wedge This tool clamping system is a standard feature that simpli es and speeds up tool setting. End Face Milling Spindle (option) The optional Quill type end face drilling spindle (BSE107) can replace the standard cross-milling spindle (BSC210). Maximum tool length is 40 mm (1.57”).


CENTERLESS GRINDING 100mm, CYLINDRICAL GRINDING 80mm, THREAD ROLLING 20TON

  • Grinding wheel & regulating wheel head fitted with precision roller/hydrodynamic bearings.
  • Regulating wheel variable speed drive in HCG - 250/200, optional in HCG - 150/100.
  • Separate motorized lubrication system for grinding wheel head with safety float switch.
  • A single lever controls table traverse, work rotation, coolant flow and rapid approach of wheel head during production runs.
  • Designed for high rates of stock removal for batch production requiring fine tolerance limits with finest surface finish.
  • For rolling machine features up to Ø Min: 3mm Ø Max: 60 mm.

AMS 1060V VMC VERTICAL MACHINE CENTERS

  • TO BE PLANNED ON MARCH,18END
  • Repeability ± 0.003mm
  • LM guideways for all three axes
  • Rigid base
  • 24 tool ATC
  • 32/32/24 m/min rapid rate for X, Y and Z axes respectively
  • Versatile machine configuration - Ideal for any machine shop
  • Ergonomically designed structure for outstanding dynamic rigidity
  • Front chip disposal system
  • Spindle power of 11/7.5 kW

INSPECTION FACILITIES


QUALITY FACILITIES

  • DIGITAL VERNIER CALIBERS - 03
  • MICROMETERS (0-25,50,75,100)mm - 04
  • BORE DIAL GAUGES (0–20mm) - 02
  • VERNIER CALIBER(0-150,200,450mm) - 02
  • DIGITAL HEIGHT GAUGE(0-300mm) - 02
  • AIR GAUGES AS PER COMPONENT - 01
  • ROUGHNESS TESTER - 01
  • SURFACE TABLE (900*900mm) - 02
  • BENCH CENTER WITH DIAL STAND - 08
  • PROFILE PROJECTOR 350mm - 02
  • LEVER DIAL / PLUNGER (0.001/ 0.01) - 08
